| Manufacturer | Supermicro |
| Product ID | SYS-5019A-FTN10P |
| CPU | Intel Atom C3758 Processor 2.2 GHz 8 Cores / 8 Threads 25W TDP, 16MB Cache |
| Chipset | SoC |
| Memory | 4 x DDR4 DIMM slots Supports up to 256GB ECC RDIMM Supports up to 64 GB ECC/Non-ECC UDIMM 2400/2133/1866/1600 MHz |
| Video | BMC integrated ASPEED AST2400 |
| Audio | N/A |
| Storage Technology | 5 x SATA3 6.0 GB/s Ports M.2: PCI-E 3.0 x2 and SATA mode |
| Connectivity | 4 x Intel C3000 SoC GbE LAN 4 x Intel I350-AM4 GbE LAN 2 x Intel I210-IS SFP GbE LAN 1 x Realtek RTL8211F Dedicated IPMI |
| Expansion Slots | 1 x PCI-E 3.0 x4 slot |
| Rear Panel I/O | 1 x RJ45 GbE Dedicated IPMI 2 x USB 2.0 8 x RJ45 GbE LAN 2 x SFP 1 x VGA |
| Front Panel I/O | 2 x USB 3.0 2 x Audio I/O 1 x Power Button 1 x USB 2.0 |
| Drive Support | 1 x M.2 2242/2280 slot (M Key, SATA, PCI-E 3.0 x2) 1 x M.2 3042/2280 slot (B Key, SATA, PCI-E 3.0 x2, USB 3.0) 1 x 3.5" Drive or 4 x 2.5" Drive (2 x 2.5" Drive space shared with PCI-E slot) |
| Cooling | 2 x 40x28mm 13K RPM PWM Fan Supports up to 3 x 40x28mm Case Fans |
| Power Supply | 200W 80 PLUS Gold Low Noise AC-DC power supply with PFC 100 - 240V, 50-60Hz, 2.6 Amp Max +5V: 8.0 Amp (Max) +5V Standby: 2.0 Amp (Max) +12V: 16 Amp (Max) -12V: 0.5 Amp (Max) +3.3V: 8.0 Amp (Max) |
| Case Dimensions | Short Depth 1U Rackmount 17.2" x 9.8" x 1.7" (in inches) 437 x 249 x 43mm |
| Environmental | Operating Temperature: 0°C to 40°C (32°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 8% to 90% (non-condensing) Non-operating Humidty: 5% to 95% (non-condensing) |
| Compliance | RoHS |
| Warranty | 1-Year Warranty on Parts and Labor |
PRODUCT ID: SYS-5019A-FTN10P
