Manufacturer | ASUS |
Product ID | RS700A-E12-RS4U-16W1G |
Model Number | RS700A-E12-RS4U |
CPU | 2 x AMD EPYC 9004 Series Processor Genoa Socket SP5, LGA 6096 Supports up to 400W TDP |
Chipset | SoC |
Memory | 24 x DDR5 DIMM slots (12 per CPU) Maximum 3TB Capacity per CPU 4800/4400 MHz Supports RDIMM / 3DS RDIMM |
Video | Aspeed AST2600 64MB |
Storage Technology | 8 x SATA 6Gb/s Ports 2 x M.2: PCI-E 4.0 x4 or SATA |
Connectivity | 4 x Intel I350-AM4 GbE LAN 1 x Realtek RTL8211F Management Port Onboard ASMB11-iKVM for KVM-over-IP |
Expansion | 1 x PCI-E 5.0 x16 slot (Full Height, Full Length) 1 x PCI-E 5.0 x16 or OCP 3.0 (Full Height, Full Length) 1 x PCI-E 5.0 x16 slot (Low Profile) 1 x PCI-E 4.0 x8 (Low Profile, Internal) |
Rear I/O | 1 x Q-Code/Port 80 LED 1 x VGA 1 x RJ45 GbE Management Port 2 x USB 3.2 (Gen1) 2 x RJ45 10G LAN |
Front Panel I/O | 1 x Power Button with LED 1 x Reset Swtich 1 x Location Switch with LED 6 x Status LED (HDD, Message, LAN) |
Drive Support | 4 x 3.5" Hotswap NVMe/SATA Drive Bays 2 x M.2 2280 slots (PCI-E 4.0 x4 or SATA) |
Power Supply | 1+1 Redundant 80 PLUS Platinum Power Supply 100-127Vac: 1600W Output 220-240Vac: 2000W Output |
Case Dimensions | 1U Form Factor 842.5 x 449 x 43.85mm 33.17" x 17.68" x 1.73" (in inches) |
Environmental | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Non-operating Humidty: 20% to 90% (non-condensing) |
Compliance | BSMI, CE, CB, C-Tick, FCC (Class A) |
Warranty | 1 Year Manufacturer's Limited Warranty |
