Manufacturer	ASUS
Product ID	RS500A-E10-RS12U
CPU	Supports AMD Epyc 7002 Series Processors Socket SP3 Up to 225W TDP
Chipset	SoC
Memory	16 x DDR4 DIMM slots 3200/2933/2666 MHz Supports up to 512GB RDIMM Supports up to 2048GB LRDIMM 3DS 8-Channel
Video	Aspeed AST2500 with 64MB VRAM
Storage Technology	CPU Integrated Backplane supports SATA/SAS/NVMe
Connectivity	2 x Intel I350-AM2 GbE LAN 1 x Management Port
Expansion Slots	1 x PCI-E 4.0 x16 slot (Gen4 x16 link, Low Profile, Half Length) 1 x OCP 2.0 Mezzanine Connector (Gen4 x16 link)
Rear Panel I/O	1 x RJ45 Management LAN Port 2 x USB 3.0 Ports 2 x RJ45 GbE LAN Ports 1 x VGA 1 x Power Switch w/ LED 1 x COM Port 1 x Q-Code/Port 80 LED
Front Panel I/O	1 x Power Switch w/ LED 6 x Status LED (Message, Location, LAN)
Drive Support	12 x 2.5" Hot Swap Drive Bays 1 x M.2 slot (22110, 2280, 2260, 2242)
Cooling	6 x 40x56mm Cooling Fans
Power Supply	1+1 Redundant 650W 80 PLUS Platinum Power Supply 100-127Vac/200-240Vac 10A/5A 50-60Hz Class I
Case Dimensions	1U Rackmount 615 x 444 x 44mm 24.21" x 17.48" x 1.73" (in inches) Weight: 11.5 kg, 25.4lbs Gross Weight: 17.5 kg, 38.6 lbs
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Non-operating Humidty: 20% to 95% (non-condensing)
Compliance	CE, FCC(Class A)
Warranty	3-Year Manufacturer's Limited Warranty
