Manufacturer	AIC
Product ID	HP201-AG
CPU	Supports Single AMD EPYC 7003 Processors per Node Supports CPU TDP 280W Socket SP3
Chipset	SoC
Memory	8 x DDR4 DIMM slots per Node 3200/2933 MHz RDIMM/LRDIMM/NVDIMM 8-Channel
Video	Aspeed AST2500
Storage Technology	Backplane: 24-port NVMe/SAS/SATA 2 x SATA connectors per Node 2 x M.2 2280 slot per Node: SATA or PCI-E x2
Connectivity	1 x RJ45 GbE Dedicated BMC Management per Node
Expansion	2 x PCI-E 4.0 x16 slots (Low Profile) 1 x OCP 2.0 Mezzanine slot (PCI-E 4.0 x16)
Rear I/O	Per Node: 1 x RJ45 GbE Dedicated BMC Management 2 x USB 3.0 1 x VGA
Front Panel I/O	Per Node: 1 x Power Button 4 x Status LED (Power, System ID, LAN BMC Alert)
Drive Support	24 x 2.5" Hotswap Drive Bays (6 x NVMe/SAS/SATA per Node) 8 x 2.5" Hotswap Drive Bays (2 x SATA per Node) 2 x M.2 2280 slots (SATA/PCI-E 3.0 x2) Per Node
Power Supply	1+1 1600W 80+ Platinum Redundant Power Supply AC Input: 200-240V, 50/60Hz, 12A (except China/Taiwan) AC Input: 200-240V, 50/60Hz, 10A (for China/Taiwan)
Cooling	4 x 60x56mm easy swap fans 1 x 60x38mm easy swap fan
Case Dimensions	2U Form Factor 17.2" x 30.7" x 3.5" (in inches) 438 x 780 x 87.5mm
Environmental	Operating Temperature: -10°C to 60°C (14°F to 140°F) Non-operating Temperature: 0°C to 35°C (32°F to 95°F) Non-operating Humidty: 5% to 95% (non-condensing) Weight: 36 kgs, 79.4 lbs
Warranty	1 Year Manufacturer's Limited Warranty
