Product ID	GA88B5631 / B5631G88V2HR-2T-N
CPU	Supports Intel Xeon Scalable Processor LGA3647 Max 165W TDP
Chipset	Intel C621
Memory	12 x DDR4-2666 DIMM Slots Supports up to 384GB RDIMM Supports up to 768GB LRDIMM Supports up to 1,536 RDIMM 3DS/LRDIMM 3DS 6 Channels, 1.2V
Video	D-Sub 15-Pin Connector Aspeed AST2500 Up to 1920x1200
Storage Technology	SATA: SATA3 6.0Gb/s RAID 0/1/10/5 (Intel RSTe) M.2: PCI-E or SATA
Connectivity	2 x Intel X550-AT2 10GbE Ports 1 x Realtek RTL8211E PHY Port
Expansion	4 x PCI-E 3.0 x16 slots (Full height, 10.5" length, double-width) 1 x PCI-E 3.0 x16 slot (Full height, half-length)
Rear I/O	1 x USB 3.0 1 x RJ45 IPMI 2 x RJ45 10Gb/s 1 x VGA
Front Panel I/O	5 x Status LEDS (Power, HDD, LAN, Warning) 1 x Power 1 x Reset 1 x UID 2 x USB 3.0
Drive Support	2 x 2.5" Hot-swap Drive Bays (Front) 2 x M.2 22110/2280
Power Supply	1600W 1+1 Redundant 80+ Platinum Power Supply AC 100-127V/12A AC 200-240V/9.48A 47-63 Hz
Case Dimensions	1U Rackmount 885 x 438 x 43.5mm 34.84" x 17.24" x 1.71" (in inches) Net Weight: 13.5 kg (30 lbs) Gross Weight: 26.5 kg (58.5 lbs)
Environmental	Operating Temperature: 10°C - 35°C (50°F - 95°F) Non-operating Temperature: -40°C - 70°C (-40°F - 158°F) In/Non-operating Humidity: 90%, non-condensing at 35°C
Compliance	RoHS 6/6 RCM Class A FCC (DoC) Class A CE (DoC) Class A VCCI Class A CB/LVD
