| Manufacturer | ASRock Rack |
| Product ID | 1U8S4E-Genoa/2T |
| CPU | Supports AMD EPYC 9004 Series Processors Socket SP5 Supports up to 300W TDP |
| Chipset | SoC |
| Memory | 8 DDR5 DIMM slots Maximum 64GB RDIMM Capacity per DIMM Maximum 512GB RDIMM-3DS Capacity per DIMM 4800 MHz |
| Video | ASPEED AST2600 DDR4 512MB VRAM |
| Storage Technology | Backplane: 12-port NVMe (PCI-E 5.0 x4)/SATA passive SAS support with additional RAID/HBA cards 2 x M.2: PCI-E 4.0 x4 |
| Connectivity | 2 x Intel X550-AT2 10GbE LAN 1 x Realtek RTL8211F GbE Dedicated Management LAN |
| Expansion | 1 x PCI-E 5.0 x16 slot (Full Height, Half Length) Supports up to 75W |
| Rear I/O | 1 x UID Button with LED 1 x RJ45 Dedicated Management LAN 2 x USB 3.2 (Gen1) 2 x RJ45 10G LAN 1 x VGA |
| Front Panel I/O | 1 x USB 3.2 (Gen1) 1 x Power Button with LED 1 x ID Button with LED 1 x System Reset 4 x Status LED (HDD, LAN, System Event) |
| Drive Support | 4 x 2.5" NVMe/SATA Drive Bays 8 x 2.5" SATA Drive Bays 2 x M.2 2280/2260/2242/2230 slot (PCI-E 4.0 x4) |
| Power Supply | 1+1 750W 80-PLUS Platinum Power Supply |
| Cooling | 6 x 40x56mm PWM Easy Swap Fans |
| Case Dimensions | 1U Form Factor 676.5 x 438 x 43.4mm 26.6" x 17.2" x 1.7" (in inches) |
| Environmental | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Non-operating Humidty: 20% to 90% (non-condensing) |
| Warranty | 1 Year Manufacturer's Limited Warranty |
PRODUCT ID: 1U8S4E-Genoa/2T
