Manufacturer	ASRock Rack
Product ID	1U2LW-X570/2L2T
CPU	Supports AMD Ryzen 5000 Series Desktop Processors Supports AMD Ryzen 4000 G-Series Processors with Radeon Graphics Supports AMD Ryzen PRO 4000 and 3000 Series Desktop Processors Supports AMD Ryzen 3000 Series Processors with Radeon Graphics Socket AM4
Chipset	AMD X570
Memory	4 x DDR4 DIMM slots Supports up to 128GB Memory ECC support with PRO technology CPU Supports up to 3200 MHz AMD Ryzen 3000 Series Processors Support up to 2666 MHz
Video	Aspeed AST2500 Note: HDMI Connector requires CPU with Radeon Graphics
Storage Technology	8 x SATA3 (1 x Support SATA DOM) Support RAID 0/1/10 1 x M.2 22110/2280/2260/2242 slot (PCI-E 4.0 x4 or SATA) 1 x M.2 2280/2260/2242 slot (PCI-E 4.0 x4 or SATA) Note: M.2 Supports PCI-E 3.0 x4 when using Picasso CPU
Connectivity	2 x Intel X710-AT2 10G LAN 2 x Intel i210 GbE LAN 1 x Realtek RTL8211E for Dedicated Management
Expansion	1 x PCI-E 4.0 x16 slot (Full Height, Half Length) Supports PCI-E 3.0 x8 when using AMD Ryzen 3000 Series Processors 1 x Slim ODD Bay
Rear Panel I/O	1 x Serial Port 1 x VGA 2 x RJ45 GbE LAN 1 x RJ45 Dedicated Management 2 x USB 3.2 (Gen1) 1 x HDMI (Requires CPU with Radeon Graphics) 2 x RJ45 10G LAN 1 x UID Button with LED
Front Panel I/O	1 x Power Switch 5 x Status LED (Power, HDD, LAN, Status) 1 x Reset Switch 2 x USB 3.2 (Gen1)
Drive Support	1 x 3.5" Drive Bay 1 x 3.5"/2.5" Drive Bay 1 x M.2 22110/2280/2260/2242 slot (PCI-E 4.0 x4 or SATA) 1 x M.2 2280/2260/2242 slot (PCI-E 4.0 x4 or SATA) Note: M.2 Supports PCI-E 3.0 x4 when using Picasso CPU
Power Supply	315W 80-PLUS Gold Power Supply 100-240V, 50-60Hz
Cooling	3 x 40x28mm PWM Fans
Case Dimensions	1U Form Factor 394 x 482.6 x 44mm 15.5" x 19" x 1.73" (in inches)
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
Warranty	1 Year Manufacturer's Limited Warranty
