Manufacturer	ASRock Rack
Product ID	1U2E-X570
CPU	Supports AMD Ryzen 5000 and 3000 Series Desktop Processors Supports AMD Ryzen 4000 and 3000 G-Series Desktop Processors with Radeon Graphics Supports AMD Ryzen PRO 5000, 4000 and 3000 Series Desktop Processors Socket AM4
Chipset	AMD X570
Memory	4 x DDR4 DIMM slots Maximum 32GB Capacity Up to 3200 MHz Note: AMD Ryzen 3000 G-Series support up to 2666MHz ECC Support with PRO Technologies Processors Only
Video	ASPEED AST2500 Onboard HDMI Requires Processors with Radeon Graphics
Storage Technology	7 x SATA Connectors 1 x SATA Connector with SATADOM Support M.2: PCI-E 4.0 x4 or SATA Note: AMD Ryzen 4000 and 3000 Series Support PCI-E 3.0
Connectivity	2 x Intel I210 GbE LAN 1 x Realtek RTL8211E Dedicated IPMI
Expansion	1 x PCI-E 4.0 x16 slot (FH, HL) Note: PCI-E 3.0 x16 when using AMD Ryzen 5000, 4000 G-Series Processors with Radeon Graphics Note: PCI-E 3.0 x8 when using AMD Ryzen 3000 G-Series Processors with Radeon Graphics
Rear I/O	1 x Serial Port 1 x VGA 2 x RJ45 GbE LAN 1 x RJ45 Dedicated IPMI 2 x USB 3.2 (Gen2) Type-A 1 x HDMI (Requires Processor with Radeon Graphics) 1 x UID Button w/ LED
Front Panel I/O	1 x Power Button 5 x Status LED (Power, HDD, LAN, System Event) 1 x Reset Button 2 x USB 3.0
Drive Support	2 x 2.5" SATA/NVMe Hotswap Drive Bays 1 x Internal 3.5" SATA Drive Bay 1 x M.2 22110/2280/2260/2242 slot (PCI-E or SATA, M Key) 1 x M.2 2280/2260/2242 slot (PCI-E or SATA, M Key)
Power Supply	315W 80-PLUS Gold Power Supply 100-240V, 50-60Hz
Cooling	4 x 40x28mm Hotswap PWM Fans
Case Dimensions	1U Form Factor 393.2 x 430 x 43.5mm 15.5" x 16.93" x 1.71" (in inches)
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Non-operating Humidty: 20% to 90% (non-condensing)
Warranty	1 Year Manufacturer's Limited Warranty
